[April 22, 1970] “Houston, We’ve had a Problem Here!” (Apollo-13 emergency in space)

April 22, 2025 Kaye Dee 2 Comments

[New to the Journey? Read this for a brief introduction!]

by Kaye Dee

We all breathed a sigh of relief when the astronauts of Apollo-13 returned to Earth safely a few days ago, after the Apollo programmes’ first (and hopefully last) inflight emergency, but superstitious people are claiming that Apollo-13 was unlucky because of a prevalence of “13s”! After all, the mission was launched at 13:13 Houston time (but somewhere in the world there will always be a place where the time is 13: something!) and the explosion that caused its inflight emergency occurred on 13 April (but only in certain timezones – it was already 14 April in Australia and most of the world east of the United States).

Don’t tell me the Apollo-13 crew were “unlucky”; in fact, they were immensely lucky that when something did go wrong they were a team with the right skills for the situation. As seasoned test pilots, the crew were experienced at working in critical situations with their lives on the line, and their professional skills as astronauts were matched by the “tough and competent” (to quote Flight Director Mr. Gene Kranz) Mission Control teams, backed by highly trained engineers and scientists – all determined to “return them safely to the Earth”, just as President Kennedy committed NASA to do when he set the goal of a manned lunar landing by 1970!

Timeline of major mission events during Apollo-13

Crew Switcheroo
The prime crew for Apollo-13 changed multiple times, the last alteration occurring just days before launch! Instead of rotating the Apollo-10 back-up crew to become the prime crew for Apollo-13 – the normal procedure – Director of Flight Crew Operations, Mr. Deke Slayton, designated astronauts Alan Shepard (Commander), Stuart Roosa (Command Module Pilot) and Edgar Mitchell (Lunar Module Pilot) as the Apollo-13 prime crew. However, although he was the first American in space, Captain Shepard had only recently returned to flight status after a lengthy medical issue. It was felt that he needed more training time, so in August 1969, his crew was swapped with the prime crew for Apollo-14.

The prime crew for Apollo 13 then became US Navy Captain James Lovell, as Commander, civilian Mr. Fred Haise as Lunar Module Pilot (LMP) and USAF Lt. Col. Ken Mattingly as Command Module Pilot (CMP).

Official crew portrait for Apollo-13. L.-R. Jim Lovell, Ken Mattingly and Fred Haise. They are shown with ancient scientific and navigation instruments hinting at the classical elements in the mission patch and callsigns

Unfortunately, just a week before launch back-up LMP Charles Duke contracted German measles (rubella) from a child and accidentally exposed both the prime and back-up crews to the disease. CMP Mattingly was found to have no immunity, and the astronauts’ medical team had serious concerns that he could become too sick to perform adequately during the flight if he began to experience symptoms of the disease.

Normally, NASA policy would dictate that the back-up crew step into the mission. However, since back-up LMP Duke also had the measles, this wasn’t feasible. Just three days before launch, the difficult decision was made to replace Lt. Col. Mattingly with Mr. Jack Swigert, the fortunately-immune back-up CMP. This made the final crew for Apollo-13 Lovell, Haise and Swigert. Astronaut Mattingly will be re-assigned to a later Apollo mission, probably Apollo 16.

The last minute Apollo-13 crew portrait, following the swap of Ken Mattingly to Jack Swigert

Who’s Who?
Although he announced his intention to retire from NASA prior to Apollo-13, 42-year-old Mission Commander James “Jim” Lovell is the world's most experienced astronaut, the record holder for the most time in space, with 572 hours aboard Gemini-7, Gemini-12 and Apollo-8!

Members of the fifth astronaut group, selected in 1966, Captain Lovell’s crewmates may have both been space rookies, but fortuitously they each had specialisations that provided vital knowledge and experience during the in-flight emergency.

Mr. Fred Haise, the Lunar Module pilot (LMP), is a 36-year-old aeronautical engineer, who was both a Marine Corps and Air National Guard fighter pilot. A civilian research pilot for NASA before his selection as an astronaut, Mr. Haise previously served as back-up LMP for Apollo-8 and 11. He is a specialist on the Lunar Module (LM), having spent fourteen months at the Grumman factory where the spacecraft are built.

Mr. John “Jack” Swigert, the Command Module Pilot (CMP), is 38 years old, with degrees in mechanical engineering and aerospace science. He has served in the US Air Force and in state Air National Guards and was an engineering test pilot immediately prior to his astronaut selection. A specialist in malfunctions of the Command and Lunar Modules, Mr. Swigert “practically wrote the book on spacecraft malfunctions.”

Knowledge from the Moon
It’s probably fortunate that, like Apollo-11, Captain Lovell’s original crew made the decision that the Apollo-13 mission patch would not carry their names: when the last minute crew swap occurred, no changes were required to the design. Instead of names, the Apollo-13 patch carries the motto “Ex Luna, Scientia”, Latin for “From the Moon, knowledge”. This references Apollo-13’s intended role as the second ‘H’-class mission, designed to demonstrate precision landing capability so that the crew could explore a specific site on the Moon. As a Navy officer, Captain Lovell derived the motto from that of the US Naval Academy, “Ex scientia, tridens ("From knowledge, sea power").

A powerful image of the Sun rising behind the horses of the god Apollo’s chariot forms the centrepiece of the design. As Apollo is the god of both the Sun and knowledge, this plays upon both the project name and the mission motto. Against the black background of space, the golden horses of Apollo prance over the Moon, their journey from the Earth (in the background) to the Moon depicted by a bright blue path. Artist Lumen Martin Winter, designer of the Apollo-13 mission patch, based the horses on a mural he previously painted for the St. Regis Hotel in New York City (below). Using Roman numerals for the mission number also complements the classical connections of the spacecraft names and callsigns.

Classical Callsigns
Captain Lovell drew upon classical mythology in selecting the Command Module callsign “Odyssey” – taken from Homer’s epic Greek poem. Since an “odyssey is “a long voyage with many changes of fortune”, it turned out to be an extremely appropriate choice indeed! The name was also a nod to the classic science fiction film "2001: a Space Odyssey".

For the Lunar Module, the crew selected the callsign “Aquarius”. Although the media have linked the callsign to the song in the musical “Hair”, it is actually meant to reference Aquarius, the cup-bearer of the Graeco-Roman gods, and bringer of water – the only water on the Moon being that carried there by the Apollo crew.

Medieval illustration of Aquarius watering the Earth

Preflight Preparations
Apollo-13’s launcher, AS-508, had some slight modifications compared to earlier Saturn-V vehicles, to prepare for the future J-class missions which will carry heavier payloads. New “spray-on insulation” was used for the liquid hydrogen propellent tanks in the S-II second stage. The rocket also carried additional fuel, as a test for future launches, making it the heaviest Saturn-V yet flown.

The intensive preparation for the Apollo-13 crew included over 1,000 hours of mission-specific training, with a much greater focus on geology, since the intended landing area in the hilly Fra Mauro formation (named for a 15th Century cartographer monk) is of significant geological interest. If rocks from this area could be dated, they might improve our understanding of the early geological history of both the Moon and the Earth. Scientist-astronaut Harrison Schmitt, himself a geologist, was heavily involved in the crew’s geological training.

Jim Lovell and Fred Haise during geology training in Hawaii

Due to the difficulty of distinguishing astronauts Armstrong and Aldrin from each other in Apollo-11 photographs, NASA introducec a means of differentiating crew members from each other on the Moon by adding red stripes on the helmet, arms and legs of the commander's spacesuit. This system will now be implemented on Apollo-14.

Experiments That Might Have Been
A major component of Apollo-13’s lunar surface activities would have been the installation of a new Apollo Lunar Surface Experiment Package (ALSEP), powered by a SNAP-27 radioisotope thermoelectric generator (RTG). This small nuclear generator contains 8.36lb of plutonium oxide. The fuel capsule is intended to withstand the heat of re-entry into the Earth's atmosphere in the event of an aborted mission, which means that Apollo-13’s RTG may have survived Aquarius’ re-entry on return to Earth, splashing down into a remote area of the southern Pacific Ocean.

Mission Commander Lovell practicing the deployment of an ALSEP instrument during training

Like Apollo-11 and 12, Apollo-13’s ALSEP included a seismometer (the Passive Seismic Experiment), which was to be calibrated by the impact of Aquarius’ ascent stage, a Lunar Atmosphere Detector (LAD) and a Dust Detector. New to the Apollo-13 instrument package was a Heat Flow Experiment (HFE), and a Charged Particle Lunar Environment Experiment (CPLEE), designed to measure solar protons and electrons reaching the Moon.

A Shakey Start
Originally scheduled for launch in March, Apollo-13 was delayed for a month while NASA re-considers how it will schedule the remaining Apollo missions out to Apollo-19, now that Apollo-20 has been axed due to President Nixon’s budget cuts.

The mission hit trouble right at the start: five and a half minutes after liftoff on Saturday 11 April (US time). The crew felt “a little vibration”, then the centre engine of the S-II stage shut down two minutes early. This required the remaining four engines to burn and additional 34 seconds longer, while the S-IVB third stage had to burn 9 seconds longer to put the spacecraft into orbit. But with the extra fuel on board for this flight, the engine failure fortunately didn’t cause any major problem.

A successful trans lunar injection burn placed Apollo-13 on course for the Moon, with the CSM and LM docking occurring 20 minutes’ later. Unlike previous lunar missions, after the LM was extracted from the S-IVB stage, the stage was not sent off into solar orbit, but targetted to impact the Moon so the vibrations could be detected by the Apollo-12 seismometer. This would later cause unexpected communications complications after the accident occurred.

Apollo-13's S-IVB stage heading towards the Moon

“We’re Bored to Tears”
With the spacecraft safely on its way to the Moon, the first phase of the flight was uneventful. Approaching 31 hours into the flight, the crew performed a burn to place Apollo 13 on a hybrid trajectory, enabling Aquarius to ultimately land at the Fra Mauro site. This change from the free-return trajectory used on earlier missions would cause later complications for returning the astronauts to Earth: on a free-return trajectory, no further engine burns were necessary to ultimately bring the spacecraft home, but a hybrid trajectory would miss Earth on its return leg, unless further burns were performed.

Apollo-13 White Team Flight Director Mr. Gene Kranz catching up on his paperwork in Mission Control during the calm before the storm

The day after launch, Mr. Swigert became worried by the realisation that, in the rush to replace Ken Mattingly, he had forgotten to file his Income Tax Return, and needed to apply for an extension! Fortunately for him, an amused Mission Control advised that “American citizens out of the country get a 60-day extension on filing; assume this applies to you.”

With Apollo-13’s telemetry showing that the spacecraft was “in real good shape”, on 13 April Capcom Joe Kerwin told the crew “We are bored to tears down here.”—a situation that was soon to change.

The Last Apollo-13 Show
Astronauts Lovell and Haise entered the LM to test its systems about an hour before a major television broadcast, scheduled for 55 hours into the mission.

With Commander Lovell acting as MC, the astronauts put on a lively show, exhibiting some of their gear such as space helmets, sleeping hammocks and newly-designed bags for drinking water inside their spacesuits. From Odyssey, Captain Lovell played tinkly lounge music using a small tape recorder, and he said it was an awesome thing to see the Moon accompanied by the theme to 2001.

Mission Control during the Apollo-13 broadcast. Astronaut Fred Haise can be seen on the big screen

Disappointingly, American television viewers had become, it seems, even more bored than Mission Control with now-“routine” missions to the Moon. None of the major US networks carried the broadcasts, although they were seen in Australia and, I believe, other countries. Marilyn Lovell and Mary Haise had to go to the Mission Control VIP viewing room to see their husbands’ half hour broadcast on television.

“Houston, We’ve had a Problem Here!”
Just nine minutes after the conclusion of the television broadcast, at 205,000 miles from Earth, an incident occurred that turned Apollo-13 from a routine mission into an emergency situation: one that the media and anxious communities in the US and around the world would intently follow as soon as the news broke!

At the request of Mission Control, Mr. Swigert stirred the cryogenic hydrogen and oxygen tanks that powered the fuel cells in the Service Module (SM). This action was followed by a “pretty large bang”, felt as a jolt through the spacecraft, accompanied by fluctuations in electrical power, attitude control thrusters firing automatically and a brief loss of communications and telemetry to Earth.

Diagram of the Service Module showing the location of the fuel cells and oxygen tanks that must have been damaged by the explosion, based on the available telemtry

CMP Swigert quickly reported "Okay, Houston, we've had a problem here," confirmed moments later by the Mission Commander, "Houston, we've had a problem. We've had a Main B Bus undervolt”. This meant that the SM’s three fuel cells were not providing sufficient voltage to the second of the Service Module’s two electrical power distribution systems

Captain Lovell momentarily thought that LMP Haise had activated Aquarius’ cabin-repressurisation valve (which Haise could have done as a joke, since its bang would startle his crewmates); CMP Swigert initially thought that a meteoroid might have struck the LM, though there was no atmospheric leakage. But voltage was dropping in both electrical buses, one oxygen tank was empty, and the other leaking, and two of the three fuel cells were failing!

Headline from Australian newspaper "The Sun" just a few hours after the accident. It references Lovell's description of gas venting from the Service Module

Looking out Odyssey’s hatch window, seeking a cause for the spacecraft thrusters to be firing erratically and affecting their course to the Moon, Captain Lovell saw “gas of some sort” venting into space. Some kind of physical rupture had definitely occurred: whatever had caused the problem, the situation was serious.

Mission Control Swings into Action
Although the Flight Controllers in Houston initially assumed that their bizarre anomalous readings from Apollo-13 had to be the result of instrumentation issues, it quickly became obvious, judging from the reports from the crew, that they were dealing with a genuine emergency.

The Mission Control White Team, led by Flight Director Gene Kranz, was on duty when the incident occurred and had to deal with the initial hours afterwards. With extensive Flight Director experience going back to the Mercury programme, and including critical phases of the Apollo-11 mission, Mr. Kranz played a crucial role in the rescue of the Apollo-13 crew.

Flight Director Gene Kranz (seated) and senior Flight Controllers during the tense period following the Apollo-13 accident

With telemetry data providing some insight into the condition of the spacecraft, and support from “backroom” teams of technical specialists, White Team worked to diagnose the problems and prioritise recovery and rescue actions.

The fuel cells needed oxygen to operate, but it was rapidly leaking away. Attempting to stem the leak, they shut down the two failing fuel cells. This immediately meant the loss of the lunar landing, as mission rules prohibited going into orbit around the Moon unless all three fuel cells were functioning. With oxygen still being lost, Mr. Kranz ordered the isolation of a small oxygen supply within the Odyssey, to retain it for use with the last remaining fuel cell, which would be needed for the final hours of the mission. The CM's batteries would be needed to power the craft during re-entry, so they were also shut down to conserve power.

Lifeboat Aquarius
Ninety-three minutes after the accident, oxygen pressure in the Command Module was dropping and Mission Control determined that the last fuel cell would soon fail as oxygen ran out, leaving the CM effectively dead. Aware of training simulations that had used the LM as a “lifeboat”, Mission Control ordered the crew to transfer to Aquarius.

Lovell, Haise and Swigert had themselves already realised that Aquarius would be needed as a lifeboat, and had commenced to power-up the Lunar Module, transferring necessary information to the LM’s guidance system. They bagged up as much water as possible from Odyssey’s supply (needed for equipment cooling as well as drinking), storing the water and food supplies in Aquarius.

The Apollo-13 crew's only view of their lifeboat Aquarius in space, drifting after it was cast loose shortly before re-entry

It was going to be a tight fit for three astronauts in a spacecraft meant for two, but the crew were fortunate that the emergency occurred when they had a fully-powered and supplied Lunar Module attached to the Odyssey. Had the explosion occurred after the lunar landing, with Aquarius jettisoned, the CM would not be able to provide enough life support to keep the astronauts alive until they returned to Earth.

Apollo-13 was being surrounded by a cloud of debris from the explosion. Communications were weak and erratic, due to probable antenna damage from debris, as well as interference from the S-IVB stage also on its way to the Moon. Its tracking beacon was operating on the same frequency as the Lunar Module, as it had not been anticipated that the LM and S-IVB stage would be communicating at the same time. (I’ll cover this situation in more detail in an article in May).

Flight Controllers conferring on how best to bring Apollo-13 safely home. Note the lack of data usually present on the big screens

“Returning Them Safely to the Earth”
Apollo-13’s new mission goal became the safe return of the crew to the Earth. Vital consumables (oxygen, electricity, and water) were assessed and rationing plans devised. Calculating the best way to get the spacecraft back to Earth before supplies were exhausted became a priority, with the mindset that “failure is not an option”.

Ultimately, the safest course of action was deemed to be putting Apollo-13 back on a free-return trajectory, firing the LM’s descent engine so that the spaceship would loop around the Moon and head back to Earth. Using the large Service Module engine was ruled out, since it was uncertain if it had been damaged by the explosion.

NASA’s “Return to Earth” trajectory specialist, Miss Poppy Northcutt, calculated a new course to carry Apollo-13 around the Moon and safely home. Anxious to assist in any way they could, other astronauts arrived at Mission Control, including Lt. Col. Mattingly, who still had not developed German measles! Some would spend time in the Apollo simulators, helping to work up needed procedures, such as powering up the Command Module for re-entry with limited electricity available.

NASA Contollers and astronauts gathered in Mission Control to assist the rescue of Apollo-13. Seated, left to right, Guidance Officer Raymond F. Teague; astronaut Edgar D. Mitchell, Apollo 14 prime crew lunar module pilot; and astronaut Alan B. Shepard Jr., Apollo 14 prime crew commander. Standing, left to right, are scientist-astronaut Anthony W. England; astronaut Joe H. Engle, Apollo 14 backup crew lunar module pilot; astronaut Eugene A. Cernan, Apollo 14 backup crew commander; astronaut Ronald E. Evans, Apollo 14 backup crew command module pilot; and M.P. Frank, a flight controller

Sixty one and a half hours after launch, Aquarius’ descent engine burn put Apollo-13 back on a free return trajectory. As it looped around the Moon, Apollo-13 captured the Guinness World Record for the farthest distance from Earth attained by a crewed spacecraft – 248,655 miles.

The Moon's far side photographed by the Apollo-13 crew. The shut down CM Odyssey can also be seen in the foreground of this view from Aquarius

I’m sure you recall the tension during those 25 minutes of radio blackout when Apollo-13 was behind the Moon. People around the world tuned into television and radio, or gathered in public spaces, eager for news, now engrossed in the gripping drama being played out in space. Would the astronauts survive? Religious leaders led congregations in prayer for their safe return.

On Their Way Home
Mission Control determined that a burn following trans-Earth injection would shave 12 hours off the flight time back to Earth and land Apollo-13 in the Pacific, where the main US recovery fleet was located. Thirteen nations (another number 13!), including the USSR, offered to provide rescue ships or aircraft for emergency recovery, should the spacecraft come down off course in the Pacific, Indian or Atlantic Oceans.

When this crucial burn took place, the debris cloud surrounding the spacecraft made it impossible to use stellar navigation to check the accuracy of the firing. However, the crew were able to use the positions of the Sun and Moon to confirm that the trajectory was on target. They were going home!

The astronauts then shut down most LM systems to conserve consumables, making for a miserable return flight: in Aquarius it was extremely cold (38 °F), dark and damp, with moisture condensing out on every surface, including the windows. The same issue occurred in Odyssey, raising concerns of short-circuits occurring when it was powered back up. Fortunately, lessons learned from the Apollo-1 fire prevented that from happening.

Mission Commander Lovell tries to sleep in the extreme cold and semi-darkness of the Lunar Module

The crew slept poorly, eating and drinking little (cold frankfurters and water for dinner, anyone?). They lost weight, with Mr. Haise developing a urinary tract infection, apparently from dehydration.

Putting a Square Peg in a Round Hole
A new problem arose during the return journey – with three astronauts in the LM, dangerous levels of carbon dioxide were building up in Aquarius. They were running out of lithium hydroxide canisters, designed to scrub it from the air, and the square canisters used in Odyssey were not compatible with the round openings in Aquarius!

Jack Swigert, with assistance from Jim Lovell (just out of frame) assembles the connections for the makeshift CO2 scrubbing device nicknamed "the mailbox", which is box shaped object beside Swigert

NASA engineers fortunately found a way to fit “a square peg in a round hole,” using only items available on the spacecraft. After the instructions for building the device were radioed up, Swigert and Haise constructed it and carbon dioxide levels began dropping immediately.

The Final Leg
Apollo-13 showed a tendency to drift slowly off course, and two more mid-course correction burns were needed to keep the spacecraft within the safe re-entry flight path. Just after 138 hours into the mission, the crew jettisoned the SM from the command module, allowing the astronauts to see and photograph the explosion area for the first time. They were shocked by the extent of the damage they saw and concerned that the explosion might have damaged the heatshield.

The astronauts' only view of the Service Module, showing the extent of the damage caused by the explosion, which blew out an entire side panel.

Moving back into Odyssey, the astronauts then reactivated its life support systems, while retaining Aquarius until about 70 minutes before entry. With no heatshield of its own, the LM could not safely re-enter, but as it drifted away, watched sadly by the crew, Capcom Kerwin offered an epitaph from Mission Control: “Farewell Aquarius, and we thank you”.

There's no place like home! Earth taken from Apollo-13 in the final stages of its return from the Moon

Home at Last!
At last, on April 17 (US time),142 hours after launch, Apollo-13 re-entered Earth’s atmosphere. Its shallow re-entry path lengthened the usual four-minute radio communications blackout to six minutes, causing Mission Control to briefly fear that the CM's heat shield had failed. But Odyssey had survived and splashed down safely in the South Pacific Ocean south-east of American Samoa, just four miles from the recovery ship, USS Iwo Jima: total flight time: 5 days, 22 hours, 54 minutes and 41 seconds. Mission Control erupted in cheers!

While the world rejoiced at their safe return, the exhausted Apollo-13 crew stayed overnight on the recovery ship, without undergoing quarantine since they did not land on the Moon.

Exhausted but elated, the Apollo-13 crew are formally welcomed aboard the recovery ship, USS Iwo Jima as returning heroes after their space ordeal

The astronauts flew to Pago Pago in American Samoa the next day, then on to Hawaii, where they were re-united with their wives and President Nixon awarded them the Presidential Medal of Freedom, the highest US civilian honour. The Presidential Medal of Freedom was also awarded to the Apollo-13 Mission Operations Team, for their efforts in ensuring the safe return of the Apollo-13 crew. After staying overnight in Hawaii, Capt. Lovell, Mr. Haise and Mr. Swigert have now returned to Houston to be re-united with their families.

Returning heroes after their space ordeal. the Apollo-13 crew stand proudly with President Nixon after being awarded the Presidential Medal of Freedom

At present, the cause of the explosion that crippled Apollo-13 is unknown, so I will leave the speculation until my follow-up article in May, talking more about Apollo-13’s epic journey. I’d like to end here with the words of President Nixon, during the Presidential Medal of Freedom presentation: “You did not reach the Moon, but you reached the hearts of millions of people on Earth by what you did.”

The astronauts only learned about the extent of the pubic reaction to their emergency after they returned to Earth!

[New to the Journey? Read this for a brief introduction!]

Follow on BlueSky

2 Comments Leave A Comment

Science / Space Race

[January 22, 1969] NASA’s Christmas Gift to the World Part 2 (Apollo 8 continued)

January 22, 2024 Kaye Dee Leave a comment

by Kaye Dee

Last month, I began this article just hours after the crew of Apollo 8 returned safely to the Earth from their historic mission around the Moon. But even while the mission was in progress, I felt that it might be best to wait to tell the story of the lunar flight in detail, until it could be illustrated with the photographs taken by Col. Borman, Major Anders and Capt. Lovell during their epic journey – images whose breathtaking full-colour views were only hinted at in the low-resolution b/w television broadcasts and the astronauts’ excited descriptions of what they were seeing during the mission.

"Oh my God!" is what Astronaut William Anders said just before he took this awe-inspiring photograph of the Earth rising over the Moon, as seen from lunar orbit. That was my exact response – and yours, too, I expect – on first seeing this incredible sight. I confidently predict that this amazing view will become one of the defining images of the Space Age

Now that we can see for ourselves the awesome sights that the Apollo 8 crew witnessed, I think I made the right call.

On Course for the Moon
We left Apollo 8 on the way to the Moon, after a successful translunar injection. Just 30 minutes later, the CSM separated from the S-IVB stage, which was ordered to vent its remaining fuel to change the stage’s trajectory. The S-IVB gradually moved away from the CSM and is now in orbit around the Sun.

Fuel venting isn't visible in this image of the jettisoned S-IVB stage, but small debris from the separation can be seen floating around it. Although Apollo 8 carried no Lunar Module, this shot shows the LM test article contained in the S-IVB stage

As the crew rotated their spacecraft to view the jettisoned stage, they had their first views of the Earth as they moved away from it—the first time human eyes have been able to view the whole Earth at once. The perspectives of the two images below, taken less than 45 minutes apart, help us gain an impression of how fast the Apollo spacecraft was travelling (around 24,200 mph).

Taken just around the time of TLI, this view from high orbit shows the Florida peninsula, with Cape Kennedy just discernible, and several Caribbean islands

The view of Earth after S-IVB stage separation. From the Americas to west Africa, and from daylight to night, for the first time humans could see their entire planet at a glance!

Mission Commander Borman has said that he thought this must be how God sees the Earth, while Astronaut Lovell felt he was driving a car into a dark tunnel and was watching the entrance dwindle into a distant speck! But perhaps Major Anders best summed up the awesome view: “How finite the Earth looks. Unlike photographs people see there’s no frame around it. It’s hanging there, the only colour in the black vastness of space, like a dust mote in infinity.”

On the way to the Moon, the CSM adopted the PTC (Passive Thermal Control) or “barbecue” mode tested on Apollo 7, slowly rotating the spacecraft to keep temperatures evenly distributed over its surface. As the CSM turned, every so often the Earth would appear in one of the windows, making the astronauts aware that they were travelling away from their home planet: it became steadily smaller, until eventually they could cover the whole Earth with a thumb.

Where No Man Has Gone Before
I’m stealing that wonderful Star Trek catch phrase because soon after the S-IBV jettison, Apollo 8 surpassed the altitude record set by Gemini 11 in 1966 and was truly setting out into that “new ocean” of space only previously traversed by unmanned probes.

The coast to the Moon was relatively uneventful, with only a few issues arising, including some window fogging, like that experienced on Apollo 7, and a bout of space sickness that it was initially feared might lead to the cancellation of the orbits around the Moon.

Col. Borman reported diarrhoea, nausea and vomiting (none of which you want to have in weightlessness, given the unpleasant consequences!) and both Lovell and Anders also said they did not feel too well. Dr Charles Berry, the medical director at Cape Kennedy, at first feared a 24-hour viral gastro-enteritis that might “play ping-pong”, with the crew re-infecting each other and leaving themselves too weak to carry out their complex tasks correctly. Fortunately, with longer sleep periods, medication and additional rest, the complaint cleared up and did not prove a showstopper for the mission.

The first mission status report for Apollo 8, sent to the NASA tracking stations around the world, for release to local media. Dated some 19 hours after launch, it outlines some of the activities of the early part of the coast to the Moon

A slight course correction saw the large SPS motor fired for the first time, providing a check that the spacecraft’s main propulsion system was working correctly. Had there been any problems, Apollo 8 would not have gone into lunar orbit, but looped around the Moon to return to Earth.

Out of this World Broadcasts
About halfway to the Moon, at 31 hours and 10 minutes after launch, the astronauts conducted the first of six television broadcasts during the mission. Like Mission Commander Schirra on Apollo 7, Borman was apparently not in favour of television broadcasts – holding that the weight of the camera was better used for other equipment and additional food supplies – but was overruled by NASA.

For this first deep space show, the approach was light-hearted, with the opening scenes from the spacecraft showing Capt. Lovell upside down in the lower equipment bay making jokes about preparing lunch. Bill Anders played with his weightless toothbrush, with quips from Frank Borman about his crewmate cleaning his teeth regularly. Jim Lovell sent birthday wishes to his mother. The crew tried to show us the Earth through the one of the CM windows, but without a viewing monitor, they couldn't quite capture it in their camera's field of view.

Astronaut Anders shows us his toothbrush (top) and Jim Lovell wishes his mother "Happy Birthday" (bottom) during Apollo 8's first deep space broadcast

The astronauts were disappointed to find their view of the approaching Moon was washed out by the Sun’s powerful glare. It should have been a spectacular sight to see its cratered surface increasing in size and detail as they closed in, but they were not able to get good views of the Moon until they were relatively close. However, during their second television broadcast, 55 hours into the mission, the crew of Apollo 8 were finally able to capture the Earth through one of their spacecraft's windows.

While the resolution of the image may not have been very high, this first ever live view of our planet from 180,000 miles out in space was yet another step in science fiction being made into reality! During the 25 minute broadcast, there was a delightful exchange between Lovell and Anders, with Capcom Michael Collins in Houston, wondering what a traveller from another planet would think of the view of Earth from that distance, and whether they would imagine it was inhabited.

The Apollo 8 second broadcast view of the Earth as we saw it on television (above) and how Capcom Collins saw it on his monitors in Mission Control (bottom). Would alien visitors to our solar system think anyone lived there?

Moving into the Moon's Sphere of Influence
Shortly after their second broadcast, Borman, Lovell and Anders became the first humans to leave the Earth’s sphere of gravitational influence: they were 202,825 miles from Earth and 38,897 miles from the Moon. This move into the lunar gravity field meant that soon a decision would need to be made as to whether or not Apollo 8 would go into lunar orbit, or loop around the Moon and return directly to the Earth. So concerned was Col. Borman about any trajectory perturbations that would preclude the spacecraft from achieving lunar orbit that he even checked with Houston before dumping urine overboard!

A view of the Moon, finally visible as Apollo 8 approached and prepared to go into orbit

Then came the moment to go behind the Moon – and the decision whether or not to orbit. “Apollo 8 this is Houston,” Capcom Jerry Carr called. “At 68 hours 4 minutes you are Go for LOI (Lunar Orbit Insertion).” But the necessary SPS engine burn to change the CSM's trajectory from "free return" to lunar orbit had to take place above the far side of the Moon, where Apollo 8 would be completely out of contact with the Earth.

On 24 December, just on 69 hours after lift-off, Apollo 8 slipped behind the Moon. Col. Borman was so impressed with the exact predicted timing of the loss of communication with the Earth that he joked about whether the Manned Space Flight Network had turned off its transmitters! But, in truth, the situation was very tense, as all the astronauts and Mission Control could do was wait and hope that all would go well with the burn to put Apollo 8 into lunar orbit. The Service Propulsion System engine had to work perfectly, or the astronauts would be in serious trouble.

The Manned Space Flight Network station at Honeysuckle Creek, near Canberra, was tracking Apollo 8 as it went behind the Moon and received the first signals as it re-emerged, safely in lunar orbit

Fortunately, Apollo 8 slowed in response to the 4 minute 6.9 second burn – “Longest four minutes I’ve ever spent,” according to Capt. Lovell. This put the spacecraft into a 194 x by 69 mile orbit around the Moon after a Trans-Lunar Coast of 66 hours 16 minutes and 22 seconds.

Round (and Round) the Moon
Safely in orbit, the plan was for Apollo 8 to make 10 orbits around the Moon over a twenty hour period. Even though the far side of the Moon was first seen as far back as 1959, by the USSR's Luna 3, the first order of business was for the crew to observe the far side surface for themselves. The three astronauts were stunned by the crater-pitted Moonscape sliding below them, revealing a tortured terrain so unlike the familiar face of the Moon. Out of contact with the Earth, totally isolated from home, Borman, Lovell and Anders forgot their mission for a few moments to press their faces against the CM windows and soak up the sights!

The astronauts were not exactly impressed with the gritty, grey, plaster-like surface they observed as they orbited the Moon. Col. Borman described it as as “[looking] like the burned-out ashes of a barbecue,” while Capt. Lovell said “It’s like a sand pile my kids have been playing in for a long time. It’s all beat up with no definition. Just a lot of bumps and holes.” Major Anders felt the surface looked "whitish-grey, like dirty beach sand with lots of footprints in it.”

Jim Lovell's "sand pile" on the Moon!

Back on Earth Mission Control held its breath, waiting for Apollo 8 to re-emerge from behind the Moon and confirm that the SPS engine had performed as planned. But once the crew were back in contact with Earth, a packed routine of surface observations was quickly established: these images comprise the bulk of the more than 800 70 mm still photographs and 700 feet of 16 mm movie film that the astronauts took during the mission. Among their tasks, the astronauts observed Earthshine (the light reflecting from Earth shining on the dark face of the Moon) – which they found provided enough light to see surface features clearly – and took detailed photographs of the area within the Sea of Tranquillity where, all going to plan in the next few months, the Apollo 11 mission will make the first manned lunar landing.

On the second orbit, Apollo 8's 12 minute long third television broadcast was almost entirely dedicated to allowing us back on Earth to see the astronauts' view of the Moon. Even when it was difficult to see much detail in the views of the lunar surface passing below the spacecraft, this broadcast made us, as it were, part of the mission.

View of the Moon's surface during the third Apollo 8 television broadcast

Earthrise
Busy with lunar surface observations, during their first three orbits the Apollo 8 crew failed to even notice an incredible sight. It was not until their fourth orbit that the astronauts experienced perhaps the most sublime view provided by space exploration to date – the vision of the Earth rising above the lunar horizon!

On this fourth orbit, a navigation sighting meant that the CSM was rolled to look outwards into space instead of down towards the Moon's surface. As the lunar horizon came into view, the astronauts witnessed a magnificent sight – the cloud-mottled blue orb of the Earth swimming into their view.

Awestruck, they scrambled so quicky to capture the vision that no-one is quite sure now who took which picture, although it seems that Col. Borman may have snapped the first black and white photograph, and Bill Anders a number of breathtaking colour images of the Earthrise.

Apollo 8's Earthrise images are usually published oriented with the lunar horizon at the bottom, as that is how we are used to seeing the Moon rising over the horizon on Earth. But the orientation of astronauts' orbit meant that they actually saw the Earth appearing to rise 'sideways', as seen in this original version of Major Anders' photograph

While Apollo 8 isn't the first space mission to capture the vista of the Earth rising over the Moon – that honour goes to Lunar Orbiter 1 – the impact of the superior quality and colour of the astronaut's photographs is profoundly inspiring, and Major Anders' evocative Earthrise image is already well on its way to becoming the most reproduced image of the Space Age so far.

This spread from the 15 January issue of the Australian Women's Weekly is just one example of thousands of magazine and newspaper articles already featuring the Earthrise photograph and Apollo 8's other amazing pictures

I'm so moved by the Earthrise image that I find it hard to put all my feelings into words, but perhaps those I quoted above from Astronaut Anders go some way to expressing them, as do Captain Lovell's similar thoughts on the view: “The vastness up here of the Moon is awe inspiring. It makes you realize just what you have back there on Earth. The Earth from here is a grand oasis in the blackness of space.”

This view of the living Earth in the immensity of the Cosmos truly brings home to us the fragility and isolation of our home planet and its finite resources, providing the visual encapsulation of the expression "Spaceship Earth" popularised over the past few years by Buckminster Fuller among others. The environmental movement needs to utilise the power of this image to help encourage us all to be better stewards of the Earth and preserve our environment, so necessary for our survival, for future generations.

"Something Appropriate"
Acutely aware of the historic nature of the Apollo 8 mission, NASA wanted the astronauts to “do something appropriate” for their fourth television broadcast. Due to occur on the ninth lunar orbit, this finale to Apollo 8’s time at the Moon was scheduled for late evening on Christmas Eve in the United States (comfortably at lunchtime on Christmas day for us here in Australia). The program was to be transmitted via satellite to 64 countries (where it was seen or heard by an estimated one billion people!), so it was a major global event, comparable to 1967’s Our World broadcast.

What would be appropriate for such an international audience? The astronauts wanted to present something spiritually significant and memorable, but not overtly religious, that would be relevant at Christmas to both Christians and the millions of non-Christians who would be tuning into the broadcast. It seems that the wife of a journalist (I’m sorry, I don’t know her name) suggested that they read from the opening of the Book of Genesis, which has meaning for many of the world’s religions and expresses concepts relevant to many other faiths. The crew liked this idea and planned to incorporate it into their broadcast.

A view of the Moon seen by the audience on Earth while the crew of Apollo 8 read from the Book of Genesis

The fourth telecast from Apollo 8 began with the astronauts talking about their impressions of the Moon and the experience of being in lunar orbit. Following some views of the lunar terrain, described by the astronauts as they passed over, Major Anders said that the crew had a message for everyone on Earth. In turn, Anders, then Capt. Lovell and finally Col. Borman read the first 10 verses of Genesis, as we watched the Moon’s surface pass by, with a view through one of the CM windows. Borman then ended the broadcast with “And from the crew of Apollo 8, we close with good night, good luck, a Merry Christmas and God bless all of you – all of you on the good Earth.” I watched this transmission at lunch with my sister’s family: it left us all profoundly moved.

Families around the world gathered on Christmas Eve/Christmas Day (depending on where you were!) to watch Apollo 8's broadcast

Set Course for Earth
Two and a half hours after the end of the fourth television broadcast, on Apollo 8’s tenth lunar orbit, it was time to perform the trans-Earth injection (TEI). This manoeuvre was even more critical than the one which had brought the CSM into orbit around the Moon: if the SPS engine failed to ignite, the crew would be stranded in lunar orbit. Like the previous SPS burn, this critical firing had to occur above the far side of the Moon, once again out of contact with the Earth. Despite all the telemetry indicating that the SPS was in good shape, tension was high while the spacecraft was behind the Moon, but the burn was perfect and Apollo 8 re-emerged exactly on schedule 89 hours, 28 minutes, and 39 seconds after launch.

It was Christmas Day, and when voice contact was restored with Houston, Lovell announced to the world, “Please be informed, there is a Santa Claus” – apparently for the benefit of one his sons, who had asked before the flight if his father would see Santa while visiting the Moon.

A view inside the Command Module, during the fifth Apollo 8 television broadcast

At about 100 hours and 48 minutes after launch, Apollo 8 crossed back into the Earth’s sphere of influence and began gradually speeding up. After the astronauts carried out the only required midcourse correction at 104 hours into the mission, the crew had some time to relax before their fifth television broadcast. During this 10 minute transmission, they gave viewers a tour of the spacecraft, showing how they lived in the weightless environment.

An image from the fifth broadcast taken directly from a monitor at the Honeysuckle Creek tracking station. It shows Bill Anders demostrating how to prepare a meal

A Christmas Dinner to Remember
After the broadcast, the crew were finally free to tuck into their Christmas dinner – and found a surprise in their food locker. It was a specially packed Christmas dinner wrapped in foil and decorated with red and green ribbons! A gift from Director of Flight Crew Operations Deke Slayton, the special meal included dehydrated grape drink, cranberry-applesauce, and coffee, as well as a new “wetpack” containing turkey and gravy. Also hidden with the surprise dinner, the astronauts found small presents from their wives.

Slayton also included three miniature bottles of brandy with the meal, although Borman decided that they should be saved until after splashdown!

The astronauts thought the food was delicious, more like a TV dinner, and much more appetising than the food they had been eating on the mission. In fact, the crew had found their meals so unappealing that they had been under-eating throughout the mission, so their turkey dinner was a real morale booster.

The new “wetpack” container is breakthrough in space food development: a thermostabilized package that retains the normal water content of the food, which can be eaten with a spoon. I’ll have to write more soon about space food, as the new meals and menus that are being developed for Apollo lunar missions are a real breakthrough in astronaut nutrition.

The Final Leg
The return cruise to Earth was the quietest part of the mission for the crew, giving them time to rest after an eventful historic mission. Around 124 hours into the flight, the astronauts broadcast their sixth and final telecast, showing the approaching Earth during a four-minute broadcast.

The crew also had time to take more spectacular photographs of the Earth, such as this image of Australia as they homed in towards their eventual splashdown in the Pacific Ocean.

Re-entry is the most dangerous phase of any spaceflight, and Apollo 8 marked the first time that a manned spacecraft had returned from the Moon, re-entering the atmosphere at 24,695 miles per hour! The spacecraft had to enter the Earth’s atmosphere at an angle of 6.5 degrees, with a safe corridor only 26 miles wide – there was very little margin for error!

After jettisoning the Service module and turning the CM around so its heat shield was facing in the direction of flight, Apollo 8 entered the atmosphere, deceleration hitting the astronauts with forces up to 7 Gs, and temperatures outside the spacecraft reaching 5,000 degrees.

Apollo 8's re-entry, captured by one of NASA's Apollo Range Instrumented Aircraft that operate as airborne tracking stations

Ionized gases around the spacecraft caused a three-minute communications blackout period. But Apollo 8 came through and safely deployed its three main parachutes, splashing down in the dead of night local time, in the North Pacific Ocean, southwest of Hawaii, home safe after a momentous mission which even the crew had rated themselves as only having a 50% chance of a successful return!

Map of Apollo 8's splashdown area

Recovered by the USS Yorktown, Borman, Lovell, and Anders were in excellent health after a flight of 147 hours. They returned to Houston for several weeks of debriefing, but he success of their flight means it is now clear that the likelihood of meeting President Kennedy’s goal of a Moon landing before the end of the decade is much higher: Lt.-General Phillips, head of the Apollo programme, has already said there is a slim chance Americans could land on the Moon with Apollo 10 in May or June – one flight earlier than presently planned

After their recovery, the Apollo 8 astronauts addressed the USS Yorktown's crew, very glad to be home!

“You Saved 1968”
As I noted at the beginning of the first part of this article, 1968 was a year that saw much upheaval around the world. Yet Apollo 8 allowed the year to end on a hopeful note, with its technical triumph of the first manned mission to the Moon, its awe-inspiring views of the Earth from space, and the deeply moving “Genesis broadcast”. Its impact has been beautifully summed up in a telegram from an anonymous well-wisher to Col. Borman which simply said, “Thank you Apollo 8. You saved 1968.”

For the influence and impact of their mission, Time magazine has chosen the crew of Apollo 8 as its Men of the Year for 1968, while Life has selected the post-TLI image of the Earth for the cover its 1968 retrospective issue.

The Apollo 8 astronauts have been honoured for their successful mission with ticker tape parades in New York, Chicago and Washington, D.C; they have spoken before a joint session of Congress, and been awarded the NASA Distinguished Service Medal by President Johnson. Has Apollo 8 won the Space Race for the United States? I think it's too early to say, especially in light of the recent Soyuz 4 and 5 missions. But NASA is certainly giving the Soviet Union a run for its money!

No comments Leave A Comment

Science / Space Race

[December 28, 1968] A Christmas Gift to the World – Part 1 (Apollo 8)

December 28, 2023 Kaye Dee 2 Comments

by Kaye Dee

Commentators are already referring to 1968 as the most turbulent year of the 1960s. We’ve seen civil unrest and sectarian violence; uprisings and brutal repression; new wars and intensification of old ones; political turmoil and assassinations; drought, famine and natural disasters, just to note some of the tragedies and strife dominating the headlines.

Yet this “worst of times” has still ended on a high note, thanks to NASA’s Christmas gift to the world – the Apollo-8 mission to the Moon.

As I write, the first daring spaceflight to the Earth’s nearest neighbour was completed only a few hours ago, splashing down in the early hours of the morning here in Australia. I’m tired but elated at the successful conclusion of the mission and the safe return of the crew. This historic mission has taken another crucial step in turning the ancient dream of reaching for the stars into reality, vindicating the inspiration that readers of the Journey draw from science fiction.

Taking the World on the Journey
Thanks to the growing number of communications satellites now linking the world, almost three quarters of humanity has been able to participate vicariously in Mankind’s greatest space adventure to date. Apollo-8’s voyage has been vividly described to us through pictures, voice and the printed word by the world's journalists, and live from space by the astronauts themselves in their broadcasts during the mission.

The Earth seen through a window of the Apollo-8 Command Module during the second television broadcast en route to the Moon. I can't wait to see the much higher resolution, full colour pictures!

While we here in Australia may have missed out on some of the live broadcasts from space for technical reasons, people in Europe, the Americas, Asia and, it seems, even the nations of the Warsaw Pact have seen the view of the Earth from greater distances than ever before, live from the inside of the Apollo-8 Command Module. Around the world, spirits have been lifted and the public inspired by the courage of the Apollo-8 crew and the successful completion of their mission. I expect that, like me, many of you reading this will have been moved by the solemn reading from the Book of Genesis, a sacred text to three great religions, from lunar orbit on Christmas Day. It was a moment truly evoking “peace on earth and goodwill to men” – the spirit of Christmas – at the end of a fraught year for the world.

The Moon seen through a window of the Apollo-8 Command Module while the crew read the opening words of the Book of Genesis

I think that the full impact of Apollo-8’s mission will take some time to emerge, especially once the photographs of the sights that the astronauts described to us during their flight become available to the public in the coming weeks. For this reason, I have decided to break my coverage of Apollo-8 into two parts. The first, today, will describe the background to the mission. Once NASA begins to process and release the photographs and films taken during the flight, the second part of my mission coverage will explore the lunar flight itself in more detail, illustrated by what I’m sure will be the magnificent images captured by the crew.

From Earth Orbit to Lunar Orbit
Originally planned as an Earth orbiting mission to check out the Lunar Module (LM) necessary to land astronauts on the Moon, delays in that vehicle’s development resulted in a radical change to the Apollo-8 mission profile.

As early as August, Apollo Programme manager Mr. George Low, suggested the idea of converting the first crew-carrying flight of the mighty Saturn 5 rocket into a flight to the Moon without a LM. His initial circumlunar flight concept soon became transformed into an even bolder proposal for a lunar orbit mission, as a counter to a possible lunar flight by Soviet cosmonauts, for which the Zond-5 and 6 missions are thought to be a precursor.

A telex sent to NASA's Manned Space Flight Network at the conclusion of the Apollo-7 mission, which refers to the future lunar mission

With the successful test flight of Apollo-7, the daring plan for Apollo-8 to orbit the Moon was publicly announced on 12 November. A successful flight around the Moon would demonstrate that a manned lunar landing was achievable, and hopefully beat the USSR to placing the first humans into orbit around the Moon.

Swapping Crews
Director of Flight Crew Operations, Mr. Deke Slayton, planned early for the proposed change in the mission profile, bumping the original Apollo-8 crew to Apollo-9, since that crew had been training hard for the mission to check out the Lunar Module. Instead, the original Apollo-9 crew – Colonel Frank Borman, Captain James Lovell and Major William Anders, who had been training to test the Lunar Module in cislunar space, became the astronauts destined to fly the first manned mission to the Moon. While the new crew for Apollo-8 was announced on 19 August, the potential lunar flight plan was initially kept secret.

The Apollo-8 crew in front of the Command Module simulator. L-R Col. Borman, Major Anders, Capt. Lovell

40-year-old Col. Borman, the mission commander, and Command Module (CM) Pilot Capt. Lovell (only 11 days younger than Borman), had previously flown together on the Gemini-7 mission, during which they set a long-duration record of 14 days in space. Lovell went on to command Gemini-12, while Borman served as the astronaut representative on the Apollo-1 Fire Investigation Board. The combined space experience of these two seasoned mission commanders undoubtedly played an important role in the success of this critical NASA mission.

Rookie astronaut Major Anders, the third member of the crew, is a former US Air Force fighter pilot. He holds an advanced degree in nuclear engineering and was selected as part of NASA’s third astronaut group, with responsibilities for dosimetry, radiation effects and environmental controls. Despite its lack on this flight, Anders was designated as Lunar Module Pilot and assigned the role of flight engineer, responsible for monitoring all spacecraft systems.

Uniquely Symbolic
The unique design of the Apollo-8 mission patch has a simple elegance that perfectly symbolises the flight. The shape of the patch recalls the gumdrop shape of the Apollo CM, while the red figure 8 circling the Earth and Moon represents both the number of the mission and the free-return flight trajectory for a lunar mission.

Captain Lovell claims credit for the basic design of the patch, developing it during a flight from the Apollo spacecraft manufacturing facility in California back to Houston, after learning about the change in mission assignment.

However, he may have been inspired by earlier patch designs by Allen Stevens, who has previously been responsible for the Apollo-1 and Apollo-7 patches. Mr. Stevens used the CM shape on some of his early designs for Apollo-7. His design for the original Apollo-9 patch – that Col. Borman and his crew had apparently approved – also included a CM-shaped frame and was repurposed as an alternative Apollo-8 lunar mission design.

I’ve heard it suggested that the figure-8 design element, representing mission number and lunar trajectory, may also have been influenced by the similar use of an 8 symbol to indicate a circumlunar trajectory on documents from the Mission Planning and Analysis Division (MPAD) at the Manned Spaceflight Centre.

This logo from NASA's MPAD may have inluenced the Apollo-8 patch design. What do you think?

Rumour has it that the Apollo-8 crew wanted to name their spacecraft, but –maintaining its long-held ban on such names – NASA would not allow it. Had they been given permission to do so, Columbiad (after the massive cannon that fires a projectile spacecraft to the Moon in Jules Verne's 1865 novel From the Earth to the Moon) might have been the name the crew selected.

Countdown to a Historic Flight
The un-manned Apollo-6 Saturn 5 test flight in April experienced major problems, including severe pogo oscillation while the first stage was firing, two second-stage engine failures, and the failure of the third stage to re-ignite in orbit. Resolving these issues was a priority before Apollo-8’s Saturn-5 launcher, AS-503, could leave the ground carrying human passengers.

Pogo oscillation was a serious concern: it could not only hamper engine performance, but the g-forces it created might even injure a crew. NASA’s Marshall Space Flight Centre (MSFC) investigated the problems and determined the cause to be the similar vibration frequencies of the engines and the spacecraft, creating a resonance effect. AS-503 was therefore fitted with a helium gas system to absorb some of the vibration.

Similarly, MSFC engineers determined that fuel lines rupturing when exposed to vacuum and a mis-wired connection were the cause of the engine shutdowns. The use of suitably modified fuel lines on Apollo-8’s launch vehicle prevented these issues recurring.

The fact that the Saturn-5 thundered off Pad 39A at Kennedy Space Centre exactly as scheduled months earlier is a tribute to the 5,500 technicians and other personnel working behind the scenes to ready the launch vehicle and spacecraft for flight. Preparations for the launch were considered among the smoothest in recent years, although two equipment issues arising during the dress rehearsal countdown threatened to delay the commencement of the formal launch countdown on 16 December.

The historic first mission to the Moon was scheduled to launch at 12.51 GMT 21 December. This specific date and time would allow the crew to observe the site in the Sea of Tranquillity, where the first Apollo landing was planned to touch down, at the ideal Sun elevation of 6.7°, with shadows throwing the cratered lunar terrain into sharp relief.

As a precaution, the 103-hour countdown commenced a day early to allow time for the correction of any unseen snags and keep the lift-off on schedule. Computerised systems, now a feature of the need to support the incredible complexity of the Saturn 5 launcher, provided comprehensive data to the launch controllers giving the “go”/”no go” calls prior to launch.

The computerised Launch Control Room at Kennedy Space Centre, about three hours before launch

Avoiding the Flu – and Radiation Poisoning
With the so-called Hong Kong Flu epidemic sweeping the United States, NASA was taking no chances with the crew’s pre-launch health (especially following the issues created by astronaut Schirra’s head cold during Apollo-7). The astronauts were kept in isolation in quarters at the Kennedy Space Centre for more than a week before the flight and were immunised against the influenza virus – along with anyone likely to come into contact with them.

Emerging from pre-flight isolation into history, the Apollo-8 crew walk out to the astronaut transfer van, ready for their spaceflight

The astronaut’s pre-flight medical examination collected data for comparison with their post-flight examination. Since the Apollo-8 crew has been the first to pass through and beyond the protection of the Van Allen radiation belts, this comparison of pre- and post-flight medical data will reveal any physical changes or health effects resulting from the first human flight beyond Earth orbit.

Basic cross section of the radiation belts around Earth (not drawn to scale). The outer belt is composed of electrons, the inner belt comprises both electrons and protons.

Major Anders’ expertise in dosimetry and radiation effects has undoubtedly been relevant to this aspect of the mission, as each astronaut wore a personal radiation dosimeter which could return data back to NASA’s flight surgeons. The spacecraft also carried three passive film dosimeters recording the cumulative radiation to which the crew were subjected. Initial indications are that the radiation dosage received by the astronauts was at an acceptable level and should not preclude future missions to the Moon.

Apollo’s “Sun Screen”
Beyond the Van Allen Belts, the Apollo-8 crew was travelling in the realms of the intense and deadly radiations of deep space, particularly the streams of charged particles spewed out into the Solar System from solar flares. The astronauts would have been seriously at risk from radiation poisoning if a major solar event occurred during their spaceflight.

To ensure astronaut safety during lunar missions, NASA has established the world-wide Solar Particle Alert Network (SPAN). Stations in Houston, Texas, the Canary Islands, and Carnarvon, Western Australia, provide a 24-hour watch on the Sun, to spot dangerous solar activity. SPAN stations are operated by the US Environmental Science Services Administration (ESSA), which also collects data from twelve satellites that monitor for deadly solar flares. This space-based early-warning system is comprised of four sun-orbiting Pioneer spacecraft (including Pioneers 6, 7 and 8 carrying cosmic ray detectors developed by Australian physicist Dr. Ken McCracken) and eight Earth-orbiting Vela nuclear test detection satellites.

The ESSA SPAN facility in Carnarvon, Western Australia, equipped with both optical and radio telescopes to observe the Sun

ESSA aims to give NASA at least 24 hours’ warning of major solar eruptions, providing enough time enough to delay a launch or alter an orbit to protect the astronauts. Fortunately for Apollo-8’s important flight, the Sun smiled kindly and there was no dangerous solar activity, but future Apollo missions may be grateful for the early warning provided by NASA’s “Sun screen”.

The Whole World was Watching
Television coverage of Apollo-8’s launch was the most extensive to date. The BBC, going “live” for the first time from Cape Kennedy, provided coverage to 54 countries, across Europe and beyond in 15 languages, in a broadcast whose complexity must have rivalled its role in the Our World satellite project. Seven television networks in Britain, the United States, Japan, Canada and Mexico, provided live coverage of the launch, with NASA’s ATS-3 satellite over the Atlantic providing transmissions to Europe and ATS-1 over the Pacific, serving Japan and the Philippines. Even the Communist nations of Eastern Europe were apparently able to watch the launch, although we in Australia could not.

All eyes were trained on the sky at the crowded press site at Kennedy Space Centre as Apollo-8 lifted off

To the Moon, Alice!
When Apollo-8 launched on 21 December, Gemini veterans Borman and Lovell found the ride “less demanding than Gemini from a ‘g’ standpoint, because it didn’t reach the high ‘gs’”, they had experienced on their earlier missions. However, the ride to orbit was still “powerful and noisy… and the stagings were really kind of violent.”

Apollo-8 entered Earth orbit with the third stage still attached, its engine needed for the Trans-Lunar Injection (TLI) burn to put the spacecraft on course to the Moon. For a little over two and a half hours every system of the Command Service Module (CSM) was thoroughly checked out in orbit, to ensure it was fully operational.

Staff at the Honeysuckle Creek tracking station in Australia mark the first time humans have ventured beyond Earth orbit. The fine print of their sign reads:“In space: Borman, Lovell, Anders. On the ground: Hicks, Cross, Holland.”

Then Mission Control gave Apollo-8 the crucial permission call “You are Go for TLI”. The S-IVB stage’s engine sent the first human mission to the Moon on its way out of Earth orbit, with the spacecraft reaching escape velocity (25,000 mph) in just five minutes! As it left the Earth, Apollo-8 was placed on a “free return” trajectory, that would ensure that lunar gravity would slingshot the spacecraft around the Moon and back to Earth in the event of a failure of the CCSM’s powerful onboard engine. An amazing voyage was underway!

I am going to pause my recap of Apollo-8 at this point, and will take it up again in January, when what I anticipate will be amazing photographic imagery from the flight to the Moon and back becomes available. Please join me then. In the meantime, let me wish everyone on the Journey a Happy New Year' looking forward to an exciting 1969 – knowing that the Moon is now within our grasp!

2 Comments Leave A Comment

Science / Space Race

[November 16, 1966] A Grand Finale (Gemini 12)

November 16, 2021 Kaye Dee Leave a comment

by Kaye Dee

As I write, it’s less than a day since the splashdown of Gemini 12 brought NASA’s second manned spaceflight programme to an overwhelmingly successful conclusion, demonstrating that the Space Agency has finally mastered the art of spacewalking. It’s incredible to think that it’s only been 20 months since the first manned Gemini mission was launched, but the packed schedule of ten flights has tested out all the techniques that the space agency needs to advance to its Apollo lunar programme.

Two for the Show

Gemini 12's Command Pilot was former Naval aviator Captain Jim Lovell (left in photo above). Making his second spaceflight, Lovell previously flew on the Gemini 7 long duration mission and now holds the record for the longest time spent in space by any astronaut or cosmonaut. Pilot for this mission was rookie astronaut USAF Major Edwin “Buzz” Aldrin, who performed an unprecedented three successful extravehicular activities (EVAs) during this flight. The only member of the astronaut corps to hold a Doctorate, Aldrin is a specialist in rendezvous and docking techniques, and on this mission he put that knowledge to very good use.

A “Halloween” Patch

Gemini 12 was originally scheduled to launch on October 31, so Lovell and Aldrin had considered a Halloween theme for their mission patch. They wanted to evoke Halloween with the use of orange and black colours and also planned to show their Gemini capsule launched on a witch’s broomstick instead of a rocket! However, with the launch rescheduled to November, only the Halloween colour-scheme remained of the original concept.

The final design features the Roman numeral XII at the top of the round patch, in the position it would be on a clock-face. Just like an hour hand, the Gemini spacecraft points to the XII, a reminder that this is the final flight of the Gemini programme. The crescent Moon on the left side of the patch symbolises the ultimate goal of the upcoming Apollo programme.

Training for Weightlessness

Gemini 12's main goal was to complete three EVAs that would demonstrate that NASA had finally cracked the problem of successfully carrying out spacewalking operations, a technique crucial to the Apollo programme.

The astronauts who attempted to perform spacewalks on Gemini 9, 10 and 11, had all reported that operating in orbit was much more difficult and tiring than the simulations conducted using the KC-135 weightlessness training aircraft. They also complained that there were few handholds on the exterior of the Gemini and Agena to help them move around in Zero-G. Consequently, a new approach to training was employed for Gemini 12, which I understand was suggested by Astronaut Aldrin himself, who is a keen scuba diver.

"Buzz" Aldrin practices installing a handrail between the Gemini capsule and Agena target vehicle, in an underwater training simulation

In addition to the KC-135 flights, Aldrin trained in a large pool containing a Gemini mockup. In the pool, special weights were added to the astronaut’s spacesuit to create “neutral buoyancy,” offsetting gravity so he would neither rise nor sink, and Aldrin spent several EVA simulation training sessions of more than two hours underwater.

As well as this new training technique, more handrails and handholds were added to the Gemini capsule, along with a waist tether that would enable Aldrin to turn wrenches and retrieve experiment packages without too much effort.

Dr. Rendezvous Saves the Day, Again!

After two delays caused by technical issues, the final Gemini mission lifted off on the afternoon of November 11 US time. On its third orbit, Gemini 12 prepared to dock with the Agena target vehicle, but problems with the Gemini's onboard radar threatened to make that impossible.

Luckily, Aldrin had already developed procedures for onboard backup rendezvous techniques in the event of radar failure. Drawing on his expertise, Aldrin used a sextant and his slide rule, measuring the angle between the horizon and the Agena. Once he had confirmed the information with his rendezvous chart, Aldrin calculated corrections with the spacecraft’s computer, enabling the rendezvous and docking to be successfully accomplished.

Rendezvous with the Sun

Despite the successful rendezvous, some anomalies with the Agena’s turbopump during launch led to Mission Control cancelling a planned boost to a higher orbit, like that conducted on Gemini 11. Instead, NASA took the opportunity to have the crew photograph a solar eclipse through the spacecraft windows at the beginning of mission day two.

Using the Agena’s secondary propulsion system, Gemini 12 changed orbits to place itself above South America at the right time and location to capture the first colour images of a total solar eclipse free from the interference of the Earth’s atmosphere. During the scant eight seconds that the astronauts could view the eclipse, they snapped four images that are expected to help scientists discover the secrets of the solar corona. The pictures were taken with film sensitive to ultra-violet light, which does not penetrate through the Earth's atmosphere.

Standing Up in Space

About two hours after photographing the eclipse, Aldrin commenced his first EVA, with his head and upper body exposed to space as he stood in the open hatch above his spacecraft seat. During this “stand-up EVA”, which lasted almost two and a half hours, Aldrin took the time to accustom himself to the space environment, which it was thought would better prepare him for his later spacewalk.

One of his first jobs was to install a handrail between his hatch and the docking collar of the Agena that would aid his movements during his day three spacewalk. Aldrin mounted a camera on the side of the spacecraft, with which he took a close-up picture of himself (above), the first shot of its type ever taken! He collected a micrometeorite experiment, and took photographs of the Earth as well as ultra-violet astronomical photography.

Aldrin’s photographic tasks were part of the 14 scientific, medical, and technological experiments planned for Gemini 12. Although five experiments could not be fully completed, those that were included: frog egg growth under zero-g conditions; synoptic terrain and weather photography; airglow horizon photography; and UV astronomy and dim sky photography.

Walking and Working in Space

Gemini 12 flight day three began with some minor fuel cell and manoeuvring thruster issues that would last for the rest of the mission. They did not, however, prevent the highlight of the flight from taking place: a planned two hour tethered spacewalk by Major Aldrin. Until Gemini 12, successfully performing work outside a spacecraft was the one Gemini objective that had eluded NASA, but Aldrin exceeded even the most optimistic hopes for this flight as he performed a record two hours, nine minute and 25 second EVA.

Attached to a 30-foot umbilical cord, Aldrin used the handrail he had installed the day before to assist in attaching a 100-foot long tether between the nose of the Gemini and the Agena. With the handholds, he did not experience the problems Gordon encountered on Gemini 11. Aldrin’s approach to his spacewalk was to go slowly and carefully, resting for two-minute periods between tasks. In fact, about a dozen two-minute rest periods were built into the EVA schedule to prevent Aldrin from becoming exhausted like previous Gemini spacewalkers.

Moving to the spacecraft’s aft adapter, Aldrin supported himself with overshoe restraints and waist tethers to carry out a number of work tasks. He was able to fasten rings and hooks, connect and disconnect electrical and fluid connections, tighten bolts and cut cables. Aldrin then moved across to the Agena, where he worked at pulling apart electrical connectors and putting them together again. He also tried out a torque wrench designed for the Apollo programme.

At the completion of his spacewalk, Aldrin returned to his Gemini seat with no fatigue and all his tasks accomplished. This demonstrated that the use of neutral buoyancy training, available handholds and foot restraints on the spacecraft, and a slow and measured pace of work while in space, are the ingredients needed for future successful EVAs during the Apollo missions.

Going for a Spin

The other major task for flight day three was a repeat of the gravity-gradient stabilisation/artificial gravity experiment performed on Gemini 11. Undocking from the Agena, Gemini 12 moved to the end of the tether connecting the two vehicles and then fired its thrusters to slowly rotate the combined spacecraft. Although they had some difficulty keeping the tether taut, the astronauts were able to use centrifugal force to generate a small amount of gravity during the four hour, 20 minute exercise, and achieve gravity-gradient stabilization. After releasing the tether connected to the Agena, Gemini 12 pulled away from the target vehicle and did not re-dock with it again.

One More Time

The last day of Gemini 12’s mission began with an attempt to sight two yellow clouds of sodium particles ejected by a pair of French Centaure rockets launched from the Algerian Sahara. This experiment was designed to measure high altitude winds. Although Lovell and Aldrin could not see the clouds, they did attempt to photograph them using directional instructions from the ground. We’ll have to wait until those films are developed to see if they were successful.

Shortly afterwards, as the spacecraft came over Australia, Gemini 12’s hatch opened for the final time, and Aldrin conducted a second stand-up EVA. Lasting 55 minutes, this brought Aldrin’s total spacewalking time up to a record five hours and 30 minutes! Most of this EVA occurred as Gemini 12 passed over the night side of the Earth, so that Aldrin could aim his camera at “hot young stars”, which have stimulated the curiosity of astronomers all over the world. He also took numerous ultraviolet photographs of stars and constellations.

Mission Accomplished

After a spaceflight lasting 94 hours, 34 minutes and 31 seconds, Geminin 12 made the second computer-controlled re-entry of the programme, splashing down safely in the western Atlantic just three miles from their target, near the recovery aircraft carrier USS Wasp.

Captain Lovell and Major Aldrin have now been recovered and are on their way back to the United States for post-flight debriefing. But we already know that the Gemini 12 mission has been a fitting grand finale to the Gemini project, clearly demonstrating that NASA has achieved all the goals it set for the programme: it has now mastered rendezvous and docking, direct ascent to orbit rendezvous, long-duration spaceflight equivalent to the time of an Apollo lunar mission, and – the trickiest of all, as they discovered – the art of spacewalking.

We should not forget that Gemini has been a team effort, directly involving more than 25,000 people from NASA, the US Department of Defence, other government agencies, universities and research centres, industry and tracking station partners overseas. Everyone involved should feel great pride in the way spaceflight has been advanced in an amazingly short time.

Very soon, the manned Apollo programme will commence, and we can all hope that it will lead to a successful landing on the Moon before the end of this decade. But we should not forget that its success will stand on the shoulders of the Gemini programme.

Postscript

But where are the Russians in the race to the Moon? No Soviet manned flight has been announced since Voskhod 2 in March last year. Has the USSR withdrawn from the race? That seems unlikely, but why do they appear not to have attempted rendezvous and docking missions? Perhaps they have decided to use a different method of reaching the Moon, such as direct ascent, using a massive multi-stage rocket, without the need for orbital rendezvous? After all, as far as we can tell, they still have larger and more powerful rockets than Western nations. Only time will tell, but I think there are still many surprises in store from the USSR before either the East or West wins the Space Race!

(Want more exciting space stories? Join us for Star Trek tomorrow night at 8:30 PM (Pacific AND Eastern — two showings)!!)

Here's the invitation!

No comments Leave A Comment

Science / Space Race

[December 20, 1965] Rendezvous in space (Gemini 6 and 7)

December 20, 2020 Gideon Marcus Leave a comment

by Gideon Marcus

Ahead by a nosecone

If there was any doubt as to America's position in the Space Race, such has been dispelled this month with the amazing double mission of Geminis 6 and 7. In a single fortnight, a slew of new records has been made, leaving those of the Soviets, and those made by prior Gemini flights, in the dust.

It all started way back on October 25. The United States already had three successful two-person flights under its belt, having tested the new Gemini spacecraft with Gemini 3, experimented with spacewalking on Gemini 4, and set a space endurance record with Gemini 5.

Gemini 6, commanded by Mercury veteran Wally Schirra, would be the first test of the Agena docking adapter — an upper rocket stage remodeled to fit the nose of a Gemini so that the spacecraft could be boosted to high orbit.

Sadly for Schirra, the Agena, launched just minutes before Gemini 6's blast off time, failed to make orbit. The whole mission had to be scrubbed.

But a super-endurance flight was already in the works for December: a fourteen day slog planned for Group 2 NASA astronauts Jim Lovell and Frank Borman. Seeing how they'd just be spending two weeks jawing and sleeping, why not combine the missions of Gemini 6 and 7? While they wouldn't be able to dock, they would be able to test their orbit maneuvering engines and rendezvous techniques by getting within 20 feet of each other. Plus, it would mean four Americans in space, which would beat the Soviet record by 33%.

So it was that Gemini 7 blasted off in the afternoon of December 4 with the sweet anticipation of being joined just in space eight days later by Gemini 6A.

The long wait

Of course, Gemini 7 still had to log as many hours just in the first part of the mission than Gemini 5's astronauts did during their whole excursion. That meant a lot of endless hours. To be sure, NASA tried to occupy them by taking pictures of the Earth as they orbited, and halfway through the trip, there was a visual acuity test in which astronauts tried to pick out specially made targets on the ground.

There was also an interesting experiment in which Gemini astronauts beamed a hand laser out the window of the spacecraft, bouncing it off mirror-sided Explorer 22. This was a communications test; laser beams cannot be intercepted and are not limited by line-of-sight with the ground. Unfortunately, although the receiving station was able to see the beam, it got no useful messages from it.

Other than that, Gemini 7's crew was mostly bored and uncomfortable. They argued with NASA for several days before they were allowed to both keep their suits off. Jim Lovell wished he'd brought a book along. Things got very whiffie, and when, after week, they just couldn't delay certain bodily functions anymore, the cabin's atmosphere took a turn for the worse.

T for two

On December 12, after an early morning breakfast of steak and eggs, Schirra and his rookie companion, Tom Stafford, buckled into Gemini 6A. This would be the day they made space history by becoming the third and fourth simultaneous men in space.

It was not meant to be. At T-0, the familiar plume of smoke erupted from Gemini 6's Titan II rocket, but even before the unique groan of blast-off could reach the launch block house, the engine had already shut down. Schirra now had a microsecond to react — if the booster had left the pad at all, it would come back down, collapsing in on itself in a conflagration. But the experienced test pilot was certain the rocket hadn't moved, and he did not punch the ejector button. As a result, the mission was just delayed, rather than scrubbed.

Just four days later, the third time proved to be the charm as Gemini 6 made a perfect ascent into orbit and immediately began closing in on Gemini 7. Within just five hours, Schirra had maneuvered his spacecraft to within 100 feet, and he continued his approach. When all was said and done, both spacecraft were just one foot away from each other. Compare that to the dual flights of Vostoks 3 and 4, and later 5 and 6: while those spacecraft had gotten fairly close to one another, that was the result of accurate launching rather than onboard maneuvering. Indeed, the moment of rendezvous was the first time since Alan Shepard's 1961 launch in Freedom 7 that the entire flight crew at Mission Control was standing at their consoles.

Getting it on film

If the rest of the flights of Geminis 6 and 7 were anticlimactic for their crews, they were anything but for the anchors at CBS and NBC…or the folks on the ground glued to their boob tubes. Schirra and Stafford reentered just one day after taking off, splashing down in the Atlantic near the aircraft carrier U.S.S. Wasp. And we were there, remotely. For the first time, live cameras aboard the recovery fleet caught the action: the sight of the Gemini capsule bobbing on the placid ocean, the helicopters keeping careful watch, the divers bringing the spacecraft and its astronauts aboard ship to be feted by the thousands of crew members.

We actually got many hours of special coverage for these flights, although we had to get up very early for the splashdowns. They were mostly in color, too. I particularly liked watching CBS reporter Mike Wallace playing with the IBM computer, which was programmed for orbital mechanics calculations. And at every juncture, there were folks playing in the Gemini simulator to give us an idea what the astronauts were doing.

Who would have thought that as humanity took its first steps into space, we would be able to look over their shoulders every step of the way? All that's left is incorporating "instant replay" somehow!

What's next?

We are already halfway through the Gemini program. A total of twelve flights are planned, and seven have flown. These next flights will all take place in 1966, the first scheduled for March, which means we will have a crowded viewing schedule next year! It's got to be a fast schedule, though; the first Apollo will go up in early 1967. Next year's missions will focus on docking, extended spacewalks, and large scale orbital maneuvers — all skills we'll need for our trips to the Moon.

You can bet I'll keep tuning in to Cronkite!

The holidays are coming! Looking for the perfect gift for a niece, nephew, or other young relative? Kitra is the hopeful, found family novel that they've been waiting for. Buy a copy for them today…and perhaps one for yourself!

No comments Leave A Comment

Galactic Journey

Tag Archives: jim lovell

[April 22, 1970] “Houston, We’ve had a Problem Here!” (Apollo-13 emergency in space)

[January 22, 1969] NASA’s Christmas Gift to the World Part 2 (Apollo 8 continued)

[December 28, 1968] A Christmas Gift to the World – Part 1 (Apollo 8)

[November 16, 1966] A Grand Finale (Gemini 12)

[December 20, 1965] Rendezvous in space (Gemini 6 and 7)

55 years ago: Science Fact and Fiction
